Every sampling valve is engineered around your process conditions — not picked off a fixed catalog. In production since 2014, supplied to 100+ companies worldwide.
Discuss Your Application
Since 2014, Shanghai Li Gong Pump has designed and manufactured plunger sampling valves and fluorine-lined online sampling valves for more than 100 companies in China and abroad. Every sampling valve is engineered around your specific process conditions — connection size, pressure class, medium temperature and corrosivity — rather than picked off a fixed catalog. If you have a sampling point that off-the-shelf ball valves keep clogging or leaking, tell us the conditions and we'll design a valve for it.
Dual-seal (and optional hard-seal) design contains toxic, corrosive or high-temperature media, protecting operators from exposure during sampling.
Self-cleaning piston action prevents the jamming and blockage that plague standard ball valves under crystallizing or high-solids conditions — no missed samples, no unplanned downtime.
Every valve is engineered to your existing piping, connection size and process conditions — no re-piping, no compromise fit.
Purpose-built for industrial applications requiring precise sampling control and operator safety — typically reaction-kettle sampling under crystallizing or fouling conditions where standard ball valves jam or block. In the closed position, the piston fills the full bore and prevents any material buildup at the valve inlet; when opened, the piston retracts to allow full flow while self-cleaning the bore. A genuine dual-seal (Dual Seal) system prevents leakage, and a hard-seal option (Stellite cobalt-alloy overlay) is available for demanding or high-temperature duty.
Design highlights:
Illustrative — actual design is matched to your application.
| Connection size | 1/4"–8" (DN15–DN300) |
|---|---|
| Pressure class | 150 LB / 300 LB |
| Operating temperature | 18–280°C standard (up to 450°C with hard-seal option) |
| Materials | 304, 316/316L, 316Ti, 904L, Ta2, Monel-400, Hastelloy C |
Valve body internals are lined with PFA and sealed with a bellows for zero-leakage operation, purpose-built for online sampling of strongly corrosive acid/alkali media. Connection type (flange or thread) is designed to match your installation. This line also covers on-line sampling systems for high-purity applications — for example, PFA-lined sampling valves used in chlorosilane sampling for high-purity crystalline silicon production, solving the metal-contamination problem that standard metal sampling valves create in that process.
Focused on pumps & valves — deep applications experience across chemical, petrochemical, pharmaceutical and food industries
In-house design capability to match your exact process conditions
Silica-sol precision casting and CNC machining
Quality and compliance certifications available on request
(certificate list to be added)
Connection size, pressure, medium, temperature — send us the conditions and we'll propose a valve design.
Discuss Your Application
